Operating Weight
Bucket Capacity
Overall Length
Overall Height
Overall Width
Counterweight Clearance
Operating Weight: 2750 kg
Bucket Capacity: 0.08 m3
Overall Length: 4150 mm
Overall Height: 2510 mm
Overall Width: 1500 mm
Counterweight Clearance: 570 mm
Ground Clearance: 325 mm
Tail Swing Radius: 765 mm
Length to Center of Rollers: 1560 mm
Track Length: 1990 mm
Track Gauge: 1200 mm
Track Width: 1500 mm
Track Shoe Width: 300 mm
Max. Height of Cab: 2510 mm
Uppercarriage Width: 1450 mm
Boom Length: 2050 mm
Arm Length: 1350 mm
Max. Digging Height: 4235 mm
Max. Dumping Height: 3040 mm
Max. Digging Depth: 2800 mm
Max. Depth Cut for 2440 mm Level Bottom: 2330 mm
Max. Vertical Digging Depth: 2590 mm
Max. Digging Reach: 4780 mm
Max. Digging Reach at Ground Level:4665 mm
Min. Front Swing Radius: 2055 mm
Max. Raising Height above Ground of Dozer Blade: 325 mm
Max. Lowering Depth from Ground of Dozer Blade: 300 mm
Bucket Digging Force: 24 kN
Arm Digging Force: 14 kN
Max. Drawbar Pull: 21.5 kN
Gradeability: 57 %
Ground Pressure: 27 kPa
Travel Speed(Max/Min): 4.4/2.6 km/h
Swing Speed: 9 rpm
Fuel Tank Capacity: 26 L
Hydraulic Tank Capacity: 24 L
Model: D1105/Stage Ⅴ/Tier Ⅳ/Korea Ⅴ
Rated Power: 15.4/2400 kw/rpm
Max. Torque: 71.4/1600 N.m/rpm
Displacement: 1.123 L
Main pump
Type: Two variable plunger pump，One gear pump
Max.Flow: 2*28.8+19.2 L/min
System Pressure: 2*23.5+19 MPa
Pilot pump
Type: Quantitative gear pump
Max.Flow: 6.5 L/min
Pressure: 3.9 MPa
Flow of Aux 1（break）: 48 L/min
Flow of Aux 2: 48 MPa
– Strong power, high reliability, low noise, energy saving, and environmental protection.
– Independent research and development of arc lifting mechanism, simple structure, strong bearing capacity, good reliability
– IS0 pilot operating mode with easy operation, flexible control and good inching performance.
– International universal quick-change device with easy switching of cleaning, miling, snow-blowing, and other accessories.
– Standard bucket floating and automatic leveling function that greatly improves the work efficiency.
– All-around maintenance space that ensures easy access to the parts to be maintained and facilitates maintenance.
